Ikelite 200 Dry-Lock Housing for Nikon D7100 or D7200
Required lens port, camera, and lens not included. Shown for illustrative purposes only. DL series lens port is required, not included.
- Access to all important camera functions
- Comfortable rubber grips
- Glass optical viewfinder enhanced for underwater
- Visible o-ring seals
- Corrosion-proof solid body
- Ports available for most popular lenses
- Lens zoom gears included with housing
200ft (60m) depth rating
Made by divers in the USA
TTL Flash Exposure
The Ikelite 200 DL housing for Nikon D7100 or D7200 as shipped supports manual flash control.
Add the optional Ikelite NT2 Nikon TTL Hotshoe, #46061, Nikon TTL Converter with Ikelite Plug #4301.3, and a compatible Ikelite stobe for excellent, true, TTL flash control.
Vacuum System
A vacuum valve is included. With the optional vacuum pump with gauge, the housing seal can be tested before diving to give you confidence that the system has been properly assembled and all o-rings are intact.
Ergonomic handling
Controls are provided for every camera function except the Diopter Adjustment Control and Depth-of-field Preview Button. Flash compensation with Ikelite DS Substrobes can be accessed conveniently through the housing with a large rear dial. Shutter, video recording start/stop, and a large zoom control knob can all be comfortably reached without removing your hands from the handles. Comfortable rubberized grips provide quick-release attachment points for strobes and accessories. The tray and handles may be removed from the housing for convenience in traveling. The complete housing is neutral or slightly negative in freshwater depending on choice of lens port.
Reliable performance
A clear view of the camera and o-ring seals facilitates easy assembly and operation. Heavy-duty polycarbonate construction is durable and corrosion-free to ensure performance in even demanding conditions. Lens ports can be removed and replaced quickly with a simple positive locking system which provides visible assurance when the housing is assembled properly.
| Controls |
All important camera functions are accessible
Controls are not provided for Release Mode Dial Lock Release, AF Mode button, Focus Mode Selector, Pv Button, Fn Button, Diopter Adjustment Control, Focus Selector Lock
|
| Width |
239mm including controls |
| Height |
178mm including controls |
| Depth |
165mm including controls |
| Weight |
2.2kg without tray & handles |
| Buoyancy |
Slightly negative in freshwater |
| Depth Rating |
200ft (60m) |
| Built-in Flash |
No |
| Strobe Connection |
Ikelite digital TTL electrical bulkhead |
| Tray Mounting |
12-24 thread with 3in spacing (76mm)
|
| Main O-Ring |
0132.61 |
| Port O-Ring |
0132.45 |
| Spare Parts |
5020 Silicone lubricant in 4 1cc tubes
5512.69 O-Ring kit
0200.91 Housing body cap
9104.5 Electrical bulkhead cap
|
What's Included
- Housing
- Tray with left quick release handle
- Port hole cover
- Waterproof bulkhead cap
- Zoom grear retainer
- 5509.27 Universal zoom set up to 2.8-inch diameter
- 5509.28 Universal zoom set 2.8 to 3.0-inch diameter
- Silicone lubricant 1cc tube
- Control & push button tip accessory package
- 1 year manufacturer warranty
